Aluminium profile production

Aluminium Flat Bars

Solid profiles with a rectangular cross-section. They drill, machine and bend well, which makes them a standard choice for connection and support components. Heavier than hollow sections, but considerably more rigid.

20,000+Dies designed
90%Export
ShortLead times
Open catalogue Request a quote
Aluminium Flat Bars catalogue Open catalogue
Section drawings, dimension tables and weight per metre · opens in your browser

Where it is used

Connection and mounting platesReinforcement and support membersElectrical busbar applicationsMachined custom componentsDecorative trim and skirting

Technical data

Minimum orderDepends on the die and press — confirmed per project
LengthCut to your required length on request
Surface finishMill finish, anodised (10–25 microns), electrostatic powder coating (RAL range)
ToolingProject-based die design for sections not in our catalogue
Lead timeShort lead times, backed by our own tool shop and press capacity
ShipmentSupplied with analysis report

Flat bar size chart

Flat bars from our standard dies. a is the width, b the thickness.

CodeSize a × b (mm)kg/m
AYL 11014x30.032
AYL 11025x50.068
AYL 11036x30.049
AYL 11048x20.043
AYL 11058.8x70.166
AYL 11069.8x7.80.206
AYL 110710x20.054
AYL 110810x40.108
AYL 110910x50.135
AYL 111010x9.40.254
AYL 111110x100.27
AYL 111211x100.297
AYL 111312x20.065
AYL 111412x50.162
AYL 111512x80.259
AYL 111612x100.324
AYL 111712x120.389
AYL 111813x80.281
AYL 111913x120.421
AYL 112014x30.113
AYL 112114x3.50.132
AYL 112214x90.34
AYL 112314x140.529
AYL 112415x20.081
AYL 112515x2.50.101
AYL 112615x30.122
AYL 112715x40.162
AYL 112815x50.203
AYL 112915x100.405
AYL 113015x120.486
AYL 113115x150.608
AYL 113216x70.302
AYL 113316x80.346
AYL 113416.5x70.312
AYL 113516.3x1.80.079
AYL 113616.9x7.90.36
AYL 113717x70.321
AYL 113817x80.367
AYL 113917x170.78
AYL 114017.1x8.40.388
AYL 114118x30.146
AYL 114218x50.243
AYL 114318x70.34
AYL 114418x100.486
AYL 114519x2.80.144
AYL 114619x3.20.164
AYL 114719x3.60.185
AYL 114819x40.205
AYL 114919.5x7.50.395
AYL 115020x1.20.065
AYL 115120x1.70.092
AYL 115220x1.90.103
AYL 115320x20.108
AYL 115420x30.162
AYL 115520x3.50.189
AYL 115620x40.216
AYL 115720x50.27
AYL 115820x60.324
AYL 115920x70.378
AYL 116020x80.432
AYL 116120x100.54
AYL 116220x120.648
AYL 116320x130.702
AYL 116420x150.81
AYL 116520x201.08
AYL 116621.9x130.769
AYL 116722x70.416
AYL 116822x120.713
AYL 116922x140.832
AYL 117022.5x9.50.577
AYL 117123.5x20.127
AYL 117224.5x4.50.298
AYL 117324.7x2.70.18
AYL 117425x20.135
AYL 117525x30.203
AYL 117625x50.338
AYL 117725x80.54
AYL 117825x100.675
AYL 117925x151.013
AYL 118025x201.35
AYL 118125x221.485
AYL 118225x241.62
AYL 118325x251.688
AYL 118425.1x80.542
AYL 118525.5x20.138
AYL 118625x80.54
AYL 118726x2.50.176
AYL 118826x70.491
AYL 118926.8x3.70.268
AYL 119027x40.292
AYL 119127x80.583
AYL 119228x30.227
AYL 119328x70.529
AYL 119428x100.756
AYL 119528x161.21
AYL 119628x251.89
AYL 119729x292.271
AYL 119829.5x30.239
AYL 119930x1.50.122
AYL 120030x20.162
AYL 120130x30.243
AYL 120230x40.324
AYL 120330x50.405
AYL 120430x5.20.421
AYL 120530x60.486
AYL 120630x70.567
AYL 120730x80.648
AYL 120830x90.729
AYL 120930x100.81
AYL 121030x120.972
AYL 121130x151.215
AYL 121230x201.62
AYL 121330x252.025
AYL 121430x302.43
AYL 121531.8x24.52.104
AYL 121632x40.346
AYL 121732x100.864
AYL 121832x221.901
AYL 121933x50.446
AYL 122033.8x4.80.438
AYL 122134x80.734
AYL 122235x1.50.142
AYL 122335x2.80.265
AYL 122435x40.378
AYL 122535x50.473
AYL 122635x80.756
AYL 122735x100.945
AYL 122835x181.701
AYL 122935x17.51.654
AYL 123035x222.079
AYL 123135x302.835
AYL 123235x333.119
AYL 123335x353.308
AYL 123437x30.3
AYL 123538.1x15.91.636
AYL 123640x1.20.13
AYL 123740x20.216
AYL 123840x2.80.302
AYL 123940x30.324
AYL 124040x3.50.378
AYL 124140x50.54
AYL 124240x60.648
AYL 124340x70.756
AYL 124440x80.864
AYL 124540x101.08
AYL 124640x151.62
AYL 124740x202.16
AYL 124840x222.376
AYL 124940x252.7
AYL 125040x303.24
AYL 125140x363.888
AYL 125240x404.32
AYL 125342x9.51.077
AYL 125442x151.701
AYL 125542x323.629
AYL 125643x202.322
AYL 125744x101.188
AYL 125845x40.486
AYL 125945x80.972
AYL 126045x101.215
AYL 126145x131.58
AYL 126245x151.823
AYL 126345x222.673
AYL 126445x455.468
AYL 126546.7x101.261
AYL 126647x4.50.571
AYL 126750x1.20.162
AYL 126850x20.27
AYL 126950x30.405
AYL 127050x40.54
AYL 127150x50.675
AYL 127250x60.81
AYL 127350x81.08
AYL 127450x101.35
AYL 127550x121.62
AYL 127650x152.025
AYL 127750x182.43
AYL 127850x202.7
AYL 127950x253.375
AYL 128050x25.43.429
AYL 128150x304.05
AYL 128250x405.4
AYL 128350x456.075
AYL 128450x506.75
AYL 128550.8x31.14.266
AYL 128651x263.58
AYL 128752x81.123
AYL 128852x121.685
AYL 128952x152.106
AYL 129052x294.072
AYL 129153x192.719
AYL 129253.5x4.80.693
AYL 129354x101.458
AYL 129455x81.188
AYL 129555x355.198
AYL 129655x385.643
AYL 129755x456.683
AYL 129855x558.168
AYL 129956x1.40.212
AYL 130056x60.907
AYL 130156x203.024
AYL 130259.1x1.90.303
AYL 130360x1.30.211
AYL 130460x1.50.243
AYL 130560x20.324
AYL 130660x30.486
AYL 130760x40.648
AYL 130860x50.81
AYL 130960x60.972
AYL 131060x101.62
AYL 131160x121.944
AYL 131260x12.52.025
AYL 131360x152.43
AYL 131460x203.24
AYL 131560x254.05
AYL 131660x304.86
AYL 131760x406.48
AYL 131860x457.29
AYL 131960x508.1
AYL 132060x609.72
AYL 132165x30.527
AYL 132265x203.51
AYL 132365x407.02
AYL 132465x437.547
AYL 132565x457.898
AYL 132665x508.775
AYL 132765x6511.41
AYL 132870x10.189
AYL 132970x1.60.302
AYL 133070x61.134
AYL 133170x9.91.871
AYL 133270x101.89
AYL 133370x152.835
AYL 133470x203.78
AYL 133570x254.725
AYL 133670x295.481
AYL 133770x305.67
AYL 133870x356.615
AYL 133970x366.804
AYL 134070x407.56
AYL 134170x509.45
AYL 134270x6011.34
AYL 134370x6512.29
AYL 134470x6612.47
AYL 134570x7013.23
AYL 134673x6112.02
AYL 134775x40.81
AYL 134875x122.43
AYL 134975x153.038
AYL 135075x183.645
AYL 135175x306.075
AYL 135275x408.1
AYL 135375x5010.13
AYL 135476x326.566
AYL 135579.4x71.501
AYL 135680x1.40.302
AYL 135780x40.864
AYL 135880x51.08
AYL 135980x81.728
AYL 136080x102.16
AYL 136180x153.24
AYL 136280x204.32
AYL 136380x255.4
AYL 136480x306.48
AYL 136580x408.64
AYL 136680x5010.8
AYL 136780x6012.96
AYL 136880x7015.12
AYL 136980x8017.28
AYL 137082x8017.71
AYL 137182.5x6.21.381
AYL 137286x3.50.813
AYL 137386x6114.16
AYL 137487.2x5.21.224
AYL 137589x153.605
AYL 137690x2.750.668
AYL 137790x2.80.68
AYL 137890x2.90.705
AYL 137990x40.972
AYL 138090x61.458
AYL 138190x153.645
AYL 138290x204.86
AYL 138390x307.29
AYL 138490x409.72
AYL 138590x4510.94
AYL 138690x5012.15
AYL 138790x9021.87
AYL 138891x163.931
AYL 138991x215.16
AYL 139091x266.388
AYL 139192x4.11.018
AYL 139296x194.925
AYL 139399.8x123.234
AYL 1394100x1.50.405
AYL 1395100x30.81
AYL 1396100x41.08
AYL 1397100x51.35
AYL 1398100x61.62
AYL 1399100x71.89
AYL 1400100x82.16
AYL 1401100x102.7
AYL 1402100x123.24
AYL 1403100x154.05
AYL 1404100x184.86
AYL 1405100x205.4
AYL 1406100x256.75
AYL 1407100x308.1
AYL 1408100x4010.8
AYL 1409100x4512.15
AYL 1410100x5013.5
AYL 1411100x5414.58
AYL 1412100x5514.85
AYL 1413100x6016.2
AYL 1414100x7018.9
AYL 1415100x8021.6
AYL 1416100x10027
AYL 1417102x13.63.727
AYL 1418102x205.508
AYL 1419102x256.885
AYL 1420102x308.262
AYL 1421105x154.253
AYL 1422105x9025.52
AYL 1423106x246.869
AYL 1424110x61.782
AYL 1425110x123.564
AYL 1426110x205.94
AYL 1427110x3610.69
AYL 1428115x185.589
AYL 1429115x7021.74
AYL 1430118x288.921
AYL 1431120x82.592
AYL 1432120x103.24
AYL 1433120x123.888
AYL 1434120x154.86
AYL 1435120x206.48
AYL 1436120x258.1
AYL 1437120x289.072
AYL 1438120x309.72
AYL 1439120x4012.96
AYL 1440120x5016.2
AYL 1441120x6019.44
AYL 1442120x7022.68
AYL 1443120x10032.4
AYL 1444122x3.31.087
AYL 1445122x7223.72
AYL 1446123x4715.61
AYL 1447125x175.738
AYL 1448125x206.75
AYL 1449125x12542.19
AYL 1450130x82.808
AYL 1451130x258.775
AYL 1452132x8028.51
AYL 1453135x51.823
AYL 1454136x165.875
AYL 1455140x62.268
AYL 1456140x124.536
AYL 1457140x4517.01
AYL 1458144x7428.77
AYL 1459150x2.51.013
AYL 1460150x41.62
AYL 1461150x52.025
AYL 1462150x62.43
AYL 1463150x104.05
AYL 1464150x124.86
AYL 1465150x156.075
AYL 1466150x208.1
AYL 1467150x2510.13
AYL 1468150x3012.15
AYL 1469150x4016.2
AYL 1470150x5020.25
AYL 1471155x3213.39
AYL 1472156x41.685
AYL 1473160x156.48
AYL 1474160x208.64
AYL 1475170x83.672
AYL 1476200x105.4
AYL 1477200x126.48
AYL 1478200x158.1
AYL 1479200x2010.8
AYL 1480200x2513.5
AYL 1481200x3016.2
AYL 1482200x4021.6
AYL 1483200x5027
AYL 1484200x6032.4
AYL 1485220x84.752
AYL 1486247x2617.34

No matching size. Contact us for custom dies.

Frequently asked questions

Can flat bars be machined?

Yes. Our mechanical processing department carries out cutting, drilling and bending. Products can be delivered assembly-ready and packaged.

What is an equal-sided flat bar?

It is the term used for flat bars whose width and thickness are close enough to approach a square section. See our catalogue for the dimension table.
